| Product Name | Acer ProCreator PE320QXT | |
| Panel Specifications | Display Size | Panel Specifications |
| Panel type | IPS | |
| Max. Resolution and Refresh Rate | HDMI: 6,016 x 3,384 @ 60 Hz DP: 6,016 x 3,384 @ 60 Hz Type-C: 6,016 x 3,384 @ 60 Hz | |
| Glare | No | |
| Response Time | 4 ms (GTG) | |
| Contrast Ratio | 100,000,000:1 Max (ACM) | |
| Brightness | Native: 400 nits, HDR 600 modePeak: 600 nits | |
| Viewing Angle | 178° (H), 178° (V) | |
| Color gamut | Adobe RGB 99%/DCI-P3 99% | |
| Colors | 1.07B | |
| Bits | 8bit+FRC (10bit with dithering) | |
| System Specifications | Input Signal | System Specifications |
| VESA Wall Mounting | 100x100 mm | |
| Speaker | 5W x2 | |
| Power Supply | External (C5/C6) | |
| Tilt/Swivel/Height Adjustment/Pivot | -5°-20° / ±180° / 150mm / NA | |
| Product Name | Acer ProCreator PE320QK X | |
| Panel Specifications | Display Size | Panel Specifications |
| Panel type | QD-OLED | |
| Max. Resolution and Refresh Rate | HDMI: 3,840 x 2,160 @ 240 Hz DP: 3,840 x 2,160 @ 240 Hz Type-C: 3,840 x 2,160 @ 240 Hz | |
| Glare | No | |
| Response Time | 0.01 ms (PRT)0.1 ms (GTG) | |
| Tear Technology | AMD FreeSync™ Premium Pro NVIDIA® G-SYNC™ Compatible | |
| Contrast Ratio | 1,500,000:1 | |
| Brightness | Native: 250 nits, HDR 400 modePeak: 400 nits | |
| Viewing Angle | 178° (H), 178° (V) | |
| Color gamut | DCI-P3 99% / sRGB 99% | |
| Colors | 1.07B | |
| Bits | 10bit | |
| System Specifications | Input Signal | System Specifications |
| VESA Wall Mounting | 100x100 mm | |
| Speaker | 5W x2 | |
| Power Supply | Internal (C13/C14) | |
| Tilt/Swivel/Height Adjustment | -5°-25° / ±175° / 120mm | |
| Product Name | Acer ProCreator PE270XT | |
| Panel Specifications | Display Size | Panel Specifications |
| Panel type | IPS | |
| Max. Resolution and Refresh Rate | HDMI: 5,120 x 2,880 @ 30 Hz DP: 5,120 x 2,880 @ 60 Hz Type-C: 5,120 x 2,880 @ 60 Hz | |
| Glare | No | |
| Response Time | 4 ms (GTG) | |
| Contrast Ratio | 100,000,000:1 Max (ACM) | |
| Brightness | Native: 400 nits, HDR 600 modePeak: 600 nits | |
| Viewing Angle | 178° (H), 178° (V) | |
| Color gamut | Adobe RGB 99%/DCI-P3 99% | |
| Colors | 1.07B | |
| Bits | 8bit+FRC (10bit with dithering) | |
| System Specifications | Input Signal | System Specifications |
| VESA Wall Mounting | 100x100 mm | |
| Speaker | 5W x2 | |
| Power Supply | External (C5/C6) | |
| Tilt/Swivel/Height Adjustment/Pivot | -5°-20° / ±180° / 150mm / NA | |
| Product Name | Acer ProCreator PE160WU | |
| Panel Specifications | Display Size | Panel Specifications |
| Panel type | OLED | |
| Max. Resolution and Refresh Rate | HDMI: 2,880 x 1,800 @ 120 Hz Type-C: 2,880 x 1,800 @ 120 Hz | |
| Glare | No | |
| Response Time | 1 ms (on/off) | |
| Tear Technology | AdaptiveSync | |
| Contrast Ratio | 100,000,000:1 Max (ACM) | |
| Brightness | 400 nits | |
| Viewing Angle | 170° (H), 170° (V) | |
| Color gamut | DCI-P3 100% | |
| Colors | 1.07B | |
| Bits | 8bit+FRC (10bit with dithering) | |
| System Specifications | Input Signal | System Specifications |
| VESA Wall Mounting | 75x75 mm | |
| Speaker | 1W x2 | |
| Power Supply | Charger (Type-C) | |
| Tilt | 0°-90° | |
| Product Name | Acer PM191Q E | |
| Panel Specifications | Display Size | Panel Specifications |
| Panel type | IPS | |
| Max. Resolution and Refresh Rate | HDMI: 1,920 x 1,080 @ 100 Hz (overclock)Type-C: 1,920 x 1,080 @ 100 Hz (overclock) | |
| Glare | No | |
| Response Time | 7 ms (GTG) | |
| Contrast Ratio | 100,000,000:1 Max (ACM) | |
| Tear Technology | AdaptiveSync | |
| Brightness | 250 nits | |
| Viewing Angle | 178° (H), 178° (V) | |
| Color gamut | NTSC 72% | |
| Colors | 16.7M | |
| Bits | 8bit | |
| System Specifications | Input Signal | System Specifications |
| VESA Wall Mounting | 75x75 mm | |
| Speaker | 1W x2 | |
| Power Supply | External (non-removable plug) | |
| Tilt | 0°- 90° | |
| Product Name | Acer PD163QT | |
| Panel Specifications | Display Size | Panel Specifications |
| Panel type | IPS | |
| Max. Resolution and Refresh Rate | HDMI: 1,920 x 1,080 @ 60 Hz Type-C: 1,920 x 1,080 @ 60 Hz | |
| Glare | No | |
| Response Time | 8 ms (GTG) | |
| Contrast Ratio | 800:1 (Native) | |
| Brightness | 250 cd/m2 | |
| Viewing Angle | 170° (H), 170° (V) | |
| Color gamut | NTSC 72% | |
| Colors | 16.7M | |
| Bits | 6bit + FRC | |
| System Specifications | Input Signal | System Specifications |
| VESA Wall Mounting | 75x75 mm | |
| Speaker | 2W x2 | |
| Power Supply | Type-C Adapter | |
| Tilt | 0°- 315° | |
| Product Name | Acer PD243Y E | |
| Panel Specifications | Display Size | Panel Specifications |
| Panel type | IPS | |
| Max. Resolution and Refresh Rate | HDMI: 1,920 x 1,080 @ 100 Hz Type-C: 1,920 x 1,080 @ 100 Hz | |
| Glare | No | |
| Response Time | 4 ms (GTG) | |
| Contrast Ratio | 1,000:1 (Native) | |
| Brightness | 250 cd/m2 | |
| Viewing Angle | 178° (H), 178° (V) | |
| Color gamut | NTSC 72% | |
| Colors | 16.7M | |
| Bits | 6bit + FRC | |
| System Specifications | Input Signal | System Specifications |
| VESA Wall Mounting | 100x100 mm | |
| Speaker | 2W x2 | |
| Power Supply | Type-C Adapter | |
| Tilt | 0°- 315° | |
| Product Name | Acer PD1810 | |
| Projection System | ||
| Resolution | 4K UHD (3,840 x 2,160) | |
| Brightness | 1,000 ANSI Lumens (Standard) 800 ANSI (Eco), Compliant with ISO 21118 standards | |
| Aspect Ratio | 16:9 (Native)4:3 (Supported) | |
| Contrast Ratio | 8,000:1 | |
| Throw Ratio | Fixed | |
| Projection Lens | F = 1.94, f = 11.9 mmFixed Zoom & Auto Focus | |
| Keystone Correction | + / - 30° (Vertical, Manual, & Auto) + / - 30° (Horizontal, Manual, & Auto) 4-corner adjustment | |
| Lifespan | 20,000 Hours (Standard) 30,000 Hours (Eco) | |
| Speaker | 5W x2 | |
| Noise Level | 26 dBA (ECO) | |
| Input Interface | HDMI 2.0 (HDCP 2.2) x2USB 3.1 Type-C (Display) | |
| Output Interface | PC audio (3.5mm mini jack) DC 5V Out (USB Type-A) | |
| Dimensions | 238 x 215.4 x 127.4 mm (9.4 x 8.5 x 5.0 inches) | |
| Weight | 2.4 kg (5.28 lbs) | |
| Product Name | Acer PD1520s | |
| Projection System | ||
| Resolution | 1080p (1,920 x 1,080) | |
| Brightness | 1,200 ANSI Lumens (Standard) 4,000 LED Lumens, Compliant with ISO 21118 standards | |
| Aspect Ratio | 16:9 (Native)4:3 (Supported) | |
| Contrast Ratio | 5,000:1 | |
| Throw Ratio | 1.2 (75-inches at 2m) | |
| Projection Lens | F = 3, f = 65 mmAuto Focus | |
| Keystone Correction | + / - 30° (Vertical, Manual, & Auto) + / - 25° (Horizontal, Manual, & Auto) 4-corner adjustment | |
| Lifespan | 20,000 Hours (Standard) 30,000 Hours (Eco) | |
| Noise Level | 22 dBA (ECO) | |
| Speaker | 8 W x1 | |
| Input Interface | HDMI 2.1 (HDCP 1.4) USB2.0 Type-A x2 (share output port) | |
| Output Interface | PC audio (3.5mm mini jack) DC Out (5V/1A USB2.0 Type-A) x2 | |
| Smart Specifications | AOSP Smart systemRAM 2GB DDR16 GB eMMC | |
| Dimensions | 210 x 210 x 53 mm (8.3 x 8.3 x 2.0 inches) | |
| Weight | 1.32 kg (2.91 lbs) | |
